Semi-Auto Tube Filler & Sealer

This semi-auto tube filler and sealer is a high-performance ultrasonic packaging machine designed for precise filling and sealing of liquid and paste products. It is widely used in industries such as cosmetics, pharmaceuticals, food processing, and chemical manufacturing. The machine combines efficiency, accuracy, and stability, making it an ideal solution for medium-scale production needs.

Using advanced ultrasonic sealing technology, the machine ensures strong, durable, and clean seals without deformation. The sealing lines are smooth and clearly formed, improving both product appearance and packaging quality. This technology also eliminates the need for excessive heat, making it suitable for sensitive formulations.

The machine operates with manual tube feeding while maintaining automated functions such as color code detection, precise filling, sealing, and tail cutting. This combination provides flexibility and ease of operation while still improving production efficiency and reducing labor costs.

With multiple filling range options, the machine supports a wide variety of product volumes, from small cosmetic samples to larger industrial tubes. Its high filling accuracy ensures consistent product output, minimizing waste and improving cost efficiency.

Built with a robust structure and reliable components, the machine is designed for long-term industrial use. The ten-station rotary system allows smooth operation and stable performance, while the adjustable settings accommodate different tube sizes and materials, including plastic composite and aluminum-plastic tubes.

This machine is an excellent choice for businesses looking to upgrade their packaging process with a cost-effective, semi-automatic solution that balances productivity and control.

Key Features & Specifications:

• Model: LT-006
• Voltage: 220V / 110V
• Power: 2.2kW
• Frequency: 20kHz ultrasonic system
• Workstations: 10-station rotary system
• Filling Range: 6–60ml / 10–120ml / 25–250ml / 50–500ml
• Filling Accuracy: ±1%
• Sealing Speed: 22–25 tubes per minute
• Tube Height Range: 50–250mm
• Tube Diameter Range: 13–50mm
• Applicable Materials: Plastic composite tubes, aluminum-plastic tubes
• Air Pressure Requirement: 0.5–0.6 MPa
• Air Consumption: 0.35 m³/min
• Machine Size: 130 × 90 × 165cm
• Weight: 380kg
• Functions: Manual tube feeding, automatic filling, sealing, tail cutting, color code detection
• Ultrasonic sealing system for clean and durable sealing
